Photosynthesis in Higher Plants Notes

Study Notes

6 Topics17 Formulas11 PYQs42 Key Points

Topics

6
1

๐Ÿ“– 1. Chapter Overview

Overview

Photosynthesis is the anabolic process by which green plants use light energy to synthesize carbohydrates from carbon dioxide and water. In higher plants, it occurs mainly in chloroplasts of mesophyll cells. The chapter begins with photosynthetic pigments and chloroplast structure, then explains light reactions in thylakoid membranes where ATP, NADPH and oxygen are produced. The Calvin cycle in the stroma uses ATP and NADPH to reduce CO2 into sugars. C4 plants show special adaptations such as Kranz anatomy to reduce photorespiration. The rate of photosynthesis depends on light, CO2, temperature and water, according to Blackmanโ€™s law of limiting factors. For NEET, focus on sites, products, pigment spectra, Z-scheme, chemiosmosis, ATP/NADPH requirements, C3 vs C4 differences and limiting-factor graphs.

Key Points6
  • 1Photosynthesis is not a single reaction but a coordinated sequence of photochemical and biochemical events.
  • 2Chlorophyll a is the chief pigment; accessory pigments broaden the absorption range and protect chlorophyll.
  • 3Oxygen released during photosynthesis comes from water, not carbon dioxide.
  • 4Non-cyclic photophosphorylation produces ATP, NADPH and O2; cyclic photophosphorylation produces only ATP.
  • 5C4 plants are more efficient under high temperature, intense light and low CO2 because photorespiration is minimized.
  • 6NEET questions commonly test exact sites, sequence of electron carriers, ATP/NADPH calculations and graphs.
Memory Tricks2

Chapter Order Trick

Remember: Pigments Pick Light, Electrons Energize, Calvin Creates Carbs, C4 Cuts Photorespiration, Factors Fix Rate.

Products Split

Light reaction gives the โ€˜powerโ€™ ATP and NADPH; dark reaction uses that power to build sugar.

Examples2

Crop Productivity

A wheat field has C3 photosynthesis, while maize and sugarcane use C4 photosynthesis, giving better performance in hot bright conditions.

Aquarium Bubbles

In bright light, aquatic plants release visible oxygen bubbles because photolysis of water is active.

Reference Tables1
Sign up
Common Mistakes2

Calling Calvin Cycle a Dark Reaction

It does not directly need light, but it normally occurs in light because ATP and NADPH are supplied by the light reaction.

Wrong Oxygen Source

The oxygen evolved in photosynthesis comes from water, proved by isotope experiments, not from CO2.

Formula Cards2
Overall Photosynthesis Equation

Represents oxygenic photosynthesis in green plants. The oxygen released is derived from water.

Variables

CO2=

Carbon dioxide fixed into carbohydrate

H2O=

Electron donor split during photolysis

C6H12O6=

Glucose or carbohydrate product

O2=

Oxygen released from water

Diagrams3
Sign up
Quick Revision
2

๐ŸŒฟ 2. Photosynthetic Pigments

Overview

Photosynthesis in higher plants occurs mainly in chloroplasts of mesophyll cells. A chloroplast has a double membrane, stroma, grana and thylakoids. The light reactions occur on thylakoid membranes because they contain photosynthetic pigments and electron carriers. The Calvin cycle occurs in the stroma. Pigments include chlorophyll a, chlorophyll b, xanthophylls and carotenoids. Chlorophyll a is the chief pigment, while accessory pigments transfer absorbed light energy to it and protect chlorophyll from photo-oxidation. The absorption spectrum shows wavelengths absorbed by pigments, while the action spectrum shows wavelengths most effective for photosynthesis. Red and blue light are most effective, while green light is least effective because it is mostly reflected.

Key Points6
  • 1The thylakoid membrane is the functional platform for PS I, PS II, electron transport chain and ATP synthase.
  • 2Grana increase surface area for light harvesting and photochemical reactions.
  • 3Accessory pigments broaden the useful range of light and prevent photo-oxidative damage.
  • 4Chlorophyll a absorbs mainly blue-violet and red light.
  • 5Action spectrum roughly resembles the absorption spectrum of chlorophyll a but also reflects accessory pigment contribution.
  • 6NCERT highlight: Engelmannโ€™s experiment showed maximum oxygen evolution in blue and red regions.
Memory Tricks2

Pigment Order

Remember โ€˜A is Actual, B is Backupโ€™: chlorophyll a is chief; chlorophyll b supports it.

Spectra Trick

Plants look green because green is rejected/reflected; blue and red are used best.

Examples2

Why Leaves Are Green

Leaves appear green because chlorophyll absorbs red and blue light strongly but reflects/transmits much of the green light.

Red-Blue Grow Lights

Artificial plant growth lamps often use red and blue wavelengths because they match the peaks of photosynthetic action.

Reference Tables2
Sign up
Common Mistakes2

Absorption Spectrum vs Action Spectrum

Absorption spectrum shows light absorbed by pigment; action spectrum shows rate/effectiveness of photosynthesis.

Chloroplast Site Confusion

Do not place Calvin cycle in thylakoid. It occurs in stroma, while light reaction occurs on thylakoid membrane.

Formula Cards2
Photon Energy

Energy of light is inversely proportional to wavelength. Shorter wavelength blue light has higher energy than red light.

Variables

E=

Energy of one photon

h=

Planckโ€™s constant

c=

Speed of light

ฮป=

Wavelength of light

Diagrams3
Sign up
Quick Revision
3

โ˜€๏ธ 3. Light Reaction

Overview

The light reaction is the photochemical phase of photosynthesis and occurs in thylakoid membranes. It begins when light excites reaction centre chlorophylls in photosystems. PS II has reaction centre P680 and absorbs light first in non-cyclic electron flow. Electrons lost by PS II are replaced by photolysis of water, releasing oxygen and protons. Electrons move through carriers, helping pump protons into the thylakoid lumen. PS I has reaction centre P700; it re-excites electrons and transfers them to NADP+, forming NADPH. The proton gradient drives ATP synthase to produce ATP by photophosphorylation. Non-cyclic photophosphorylation gives ATP, NADPH and O2, while cyclic photophosphorylation around PS I produces only ATP.

Key Points6
  • 1Photosystems contain antenna pigments and a reaction centre chlorophyll a molecule.
  • 2In non-cyclic photophosphorylation, electrons move from water to NADP+ and do not return to chlorophyll.
  • 3Oxygen evolution is linked to PS II and photolysis of water.
  • 4Cyclic photophosphorylation supplements ATP when extra ATP is required.
  • 5ATP and NADPH produced in light reaction are used in Calvin cycle.
  • 6NEET often asks the exact products of cyclic vs non-cyclic photophosphorylation.
Memory Tricks2

PS Order Trick

In non-cyclic flow, PS II acts before PS I: remember โ€˜Two before One in the light runโ€™.

Cyclic Product Trick

Cyclic has a Circle: electron Comes back, so only ATP is Created.

Examples2

Solar Battery Analogy

The light reaction works like charging batteries: ATP and NADPH store usable energy for sugar synthesis.

Oxygen Evolution

Oxygen bubbles from Hydrilla in sunlight indicate active PS II-linked water splitting.

Reference Tables2
Sign up
Common Mistakes2

Assuming PS I Comes First

Although named PS I because it was discovered first, in non-cyclic electron flow PS II functions before PS I.

Adding Oxygen to Cyclic Flow

Cyclic photophosphorylation does not split water, so it does not produce oxygen or NADPH.

Formula Cards2
Photolysis of Water

Water is split in association with PS II to replace lost electrons and release oxygen.

Variables

H2O=

Source of electrons and oxygen

H+=

Protons contributing to proton gradient

eโˆ’=

Electrons supplied to PS II

O2=

Oxygen evolved as by-product

Diagrams3
Sign up
Quick Revision
4

โšก 4. Electron Transport

Overview

Electron transport in photosynthesis occurs through carriers embedded in the thylakoid membrane. In the Z-scheme, electrons from water enter PS II, are excited by light, pass through plastoquinone, cytochrome b6f and plastocyanin to PS I, are excited again and finally reduce NADP+ through ferredoxin and NADP+ reductase. As electrons move through the chain, protons accumulate inside the thylakoid lumen due to water splitting and proton pumping. This creates a proton gradient: high H+ inside the lumen and lower H+ in the stroma. ATP synthase uses this gradient to synthesize ATP, a process called chemiosmosis. The CF0 part forms the channel and CF1 catalytic head faces the stroma.

Key Points6
  • 1Water splitting increases H+ concentration in the lumen.
  • 2Cytochrome b6f contributes to proton gradient formation.
  • 3NADP+ reduction removes protons from the stroma, strengthening the gradient.
  • 4ATP is produced on the stromal side because CF1 faces stroma.
  • 5The proton gradient has both concentration and charge components.
  • 6Frequently asked NEET concept: ATP and NADPH are formed on the outer/stromal side of thylakoid membrane.
Memory Tricks2

Carrier Sequence

Water โ†’ PSII โ†’ PQ โ†’ Cyt โ†’ PC โ†’ PSI โ†’ Fd โ†’ NADP. Remember: โ€˜Water Pumps Pretty Cycles, Plants Shine For NADPHโ€™.

ATP Synthase Sides

CF1 faces stroma: โ€˜1 makes ATP for the outside stromaโ€™.

Examples2

Dam Analogy

The thylakoid membrane acts like a dam: stored proton pressure is released through ATP synthase to make ATP.

Mobile Carriers

Plastoquinone and plastocyanin behave like delivery vehicles carrying electrons between large complexes.

Reference Tables2
Sign up
Common Mistakes2

Wrong Proton Direction

Protons accumulate inside the lumen and flow back to stroma through ATP synthase.

Forgetting NADP+ Reductase

Ferredoxin does not directly become NADPH; NADP+ reductase catalyzes the final reduction.

Formula Cards2
Chemiosmotic ATP Formation

ATP synthase converts the energy of H+ movement into ATP.

Variables

ADP=

Adenosine diphosphate

Pi=

Inorganic phosphate

proton motive force=

Energy stored in H+ gradient

ATP=

Energy-rich molecule produced

Diagrams3
Sign up
Quick Revision
5

๐ŸŒฑ 5. Calvin Cycle

Overview

The Calvin cycle, also called the C3 pathway, is the carbon fixation phase of photosynthesis and occurs in the stroma of chloroplasts. It uses ATP and NADPH produced in the light reaction to convert CO2 into carbohydrate. The first stable product is 3-phosphoglyceric acid, a three-carbon compound, so it is called the C3 pathway. The cycle has three phases: carboxylation, reduction and regeneration. In carboxylation, RuBisCO fixes CO2 to RuBP, forming 3-PGA. In reduction, ATP and NADPH convert 3-PGA into triose phosphate. Some triose phosphate exits to form sugars, while most is used to regenerate RuBP. For 3 CO2, the cycle uses 9 ATP and 6 NADPH and produces one net triose phosphate.

Key Points6
  • 1RuBisCO has both carboxylase and oxygenase activity; oxygenase activity causes photorespiration.
  • 2ATP is used in both reduction and regeneration phases.
  • 3NADPH is used only in the reduction phase.
  • 4Only a small fraction of triose phosphate exits the cycle; the rest regenerates RuBP.
  • 5The Calvin cycle depends indirectly on light because ATP and NADPH come from light reactions.
  • 6NEET often tests ATP/NADPH requirement for 1 CO2, 3 CO2 and 6 CO2.
Memory Tricks2

Three Phases

Calvin cycle phases: C-R-R = Carboxylation, Reduction, Regeneration.

Energy Count

For C3: per CO2 remember โ€˜3 ATP, 2 NADPHโ€™; multiply by 3 or 6 for triose or glucose.

Examples2

Wheat and Rice

Wheat and rice are common C3 plants; their CO2 fixation directly uses the Calvin cycle in mesophyll chloroplasts.

Sugar Formation

The Calvin cycle first produces triose phosphate, which can be converted into sucrose for transport or starch for storage.

Reference Tables2
Sign up
Common Mistakes2

Wrong First Product

In C3 plants, the first stable product is 3-PGA, not glucose.

Forgetting Regeneration ATP

ATP is used not only in reduction but also in regeneration of RuBP.

Formula Cards3
Carboxylation Reaction

RuBisCO catalyzes addition of carbon dioxide to RuBP, producing two 3-carbon molecules.

Variables

RuBP=

Ribulose-1,5-bisphosphate, 5-carbon CO2 acceptor

CO2=

Carbon dioxide being fixed

3-PGA=

3-phosphoglyceric acid, first stable product

Requirement for One CO2

Useful for quick NEET calculations in the Calvin cycle.

Variables

CO2=

One molecule of carbon dioxide entering the cycle

ATP=

Energy used in reduction and RuBP regeneration

NADPH=

Reducing power for converting 3-PGA to triose phosphate

Diagrams3
Sign up
Quick Revision
6

๐ŸŒพ 6. Cโ‚„ Pathway & Photorespiration

Overview

The C4 pathway, also called Hatchโ€“Slack cycle, is an adaptation that concentrates CO2 around RuBisCO and minimizes photorespiration. It occurs in plants such as maize, sugarcane and sorghum. C4 leaves show Kranz anatomy, where bundle sheath cells form a wreath-like arrangement around vascular bundles and contain abundant chloroplasts. In mesophyll cells, PEP carboxylase fixes CO2 into oxaloacetic acid, a four-carbon compound, which is converted to malate or aspartate and transported to bundle sheath cells. There, CO2 is released and enters the Calvin cycle. Photorespiration occurs when RuBisCO binds O2 instead of CO2, wasting energy and releasing CO2. CAM plants, such as cactus, separate CO2 fixation and Calvin cycle by time, opening stomata at night.

Key Points6
  • 1PEP carboxylase has high affinity for CO2 and no oxygenase activity.
  • 2C4 plants avoid photorespiration by increasing CO2 concentration near RuBisCO.
  • 3C4 photosynthesis requires extra ATP compared with C3 photosynthesis.
  • 4Bundle sheath cells in C4 plants are rich in chloroplasts and often have reduced grana.
  • 5Photorespiration reduces photosynthetic efficiency because it consumes oxygen and releases CO2 without producing ATP or sugar.
  • 6CAM is a water-saving adaptation common in xerophytes.
Memory Tricks3

C4 Core

C4 = 4-carbon first product, 4 hot crops: maize, sugarcane, sorghum, millet.

Kranz Meaning

Kranz sounds like โ€˜crownโ€™; bundle sheath cells form a crown around the vascular bundle.

CAM Timing

CAM plants are โ€˜Cool At Midnightโ€™: they open stomata at night.

Examples2

Sugarcane

Sugarcane is a C4 plant, explaining its high productivity under tropical sunlight.

Cactus

Cactus uses CAM photosynthesis to reduce water loss by opening stomata at night.

Reference Tables2
Sign up
Common Mistakes3

Putting Calvin Cycle in Mesophyll of C4 Plants

In typical C4 plants, initial fixation occurs in mesophyll, but Calvin cycle occurs in bundle sheath cells.

Saying C4 Has No Calvin Cycle

C4 plants still use the Calvin cycle; they only add a CO2-concentrating mechanism before it.

Confusing C4 and CAM

C4 separates steps by space; CAM separates steps by time.

Formula Cards3
C4 Initial Fixation

PEP carboxylase fixes bicarbonate in mesophyll cells to form the first stable C4 acid.

Variables

PEP=

Phosphoenolpyruvate, 3-carbon CO2 acceptor

HCO3โˆ’=

Bicarbonate form of inorganic carbon

Oxaloacetate=

First stable 4-carbon product

Photorespiration Trigger

When RuBisCO acts as oxygenase, photorespiratory metabolism begins.

Variables

RuBP=

5-carbon substrate of RuBisCO

O2=

Oxygen competing with CO2

3-PGA=

Useful Calvin cycle intermediate

2-phosphoglycolate=

Photorespiratory product requiring recovery

Diagrams3
Sign up
Quick Revision
7

๐ŸŒ 7. Factors Affecting Photosynthesis

Overview

The rate of photosynthesis depends on internal factors such as chlorophyll content, leaf anatomy and enzyme activity, and external factors such as light, carbon dioxide, temperature and water. Light affects intensity, quality and duration; rate increases with light intensity until saturation. CO2 concentration is often limiting in nature because atmospheric CO2 is low. Temperature affects enzyme-controlled dark reactions more than photochemical light reactions. Water indirectly affects photosynthesis by causing stomatal closure, reducing CO2 entry and decreasing leaf hydration. Blackmanโ€™s law of limiting factors states that when a process is controlled by multiple factors, the rate is governed by the factor nearest to its minimum. NEET frequently asks graph interpretation: a plateau means another factor has become limiting.

Key Points6
  • 1At low light, light is limiting; at high light, CO2 or temperature may become limiting.
  • 2CO2 enrichment can increase photosynthesis, especially in C3 plants.
  • 3C4 plants have higher optimum temperature than C3 plants.
  • 4Very high light can damage pigments due to photo-oxidation.
  • 5Water is rarely a direct reactant-limiting factor because only a small amount is used, but it strongly affects stomata.
  • 6Limiting-factor graphs are highly important for NEET assertion-reason and statement questions.
Memory Tricks2

Major External Factors

Remember LCTW: Light, Carbon dioxide, Temperature, Water.

Blackmanโ€™s Law

Photosynthesis is like a chain: the weakest link decides the strength.

Examples3

Greenhouse CO2 Enrichment

Farmers may increase CO2 concentration in greenhouses to raise photosynthetic rate when light and temperature are adequate.

Midday Depression

On hot dry days, stomata may close at noon, reducing CO2 entry and lowering photosynthesis despite strong sunlight.

Shade Leaves

Plants growing in shade adapt to lower light intensity and may saturate at lower light levels than sun plants.

Reference Tables2
Sign up
Common Mistakes3

Misreading Plateau

A plateau does not mean photosynthesis has stopped; it means another factor is now limiting.

Thinking Water Directly Limits Usually

Water is a reactant, but its major limiting effect is indirect through stomatal closure and reduced CO2 entry.

Ignoring Temperature Optimum

Very high temperature does not always increase photosynthesis; enzymes may lose activity and photorespiration may rise.

Formula Cards3
Blackmanโ€™s Law Concept

The slowest or least available required factor controls the overall photosynthetic rate.

Variables

Rate=

Observed photosynthetic output

Limiting factor=

Factor closest to minimum requirement

Apparent Photosynthesis

Measured net oxygen release or CO2 uptake is lower than true photosynthesis because respiration occurs simultaneously.

Variables

Apparent photosynthesis=

Net measurable photosynthetic rate

True photosynthesis=

Total photosynthetic carbon fixation

Respiration=

CO2 release or O2 consumption by cellular respiration

Diagrams5
Sign up
Quick Revision

Formula Sheet

10
Overall Photosynthesis Equation

Represents oxygenic photosynthesis in green plants. The oxygen released is derived from water.

Variables

CO2=

Carbon dioxide fixed into carbohydrate

H2O=

Electron donor split during photolysis

C6H12O6=

Glucose or carbohydrate product

O2=

Oxygen released from water

Energy Requirement for One Glucose in C3 Cycle

Calvin cycle fixes six carbon dioxide molecules to produce one hexose equivalent.

Variables

ATP=

Energy currency used in reduction and regeneration

NADPH=

Reducing power used to reduce 3-PGA to triose phosphate

CO2=

Carbon source entering the Calvin cycle

Photon Energy

Energy of light is inversely proportional to wavelength. Shorter wavelength blue light has higher energy than red light.

Variables

E=

Energy of one photon

h=

Planckโ€™s constant

c=

Speed of light

ฮป=

Wavelength of light

Photosynthetic Efficiency Concept

Not all absorbed light becomes chemical energy; some is dissipated safely.

Variables

Useful energy=

Energy stored in ATP, NADPH and carbohydrates

Light absorbed=

Light captured by pigments

Photolysis of Water

Water is split in association with PS II to replace lost electrons and release oxygen.

Variables

H2O=

Source of electrons and oxygen

H+=

Protons contributing to proton gradient

eโˆ’=

Electrons supplied to PS II

O2=

Oxygen evolved as by-product

5 more formulas locked

Sign up free to access all formulas with variables and explanations.

Quick Revision

12 Sign up to access

Unlock 12 Quick Revision Points

Sign up free to access all content, practice PYQs, and get AI explanations.

NEET PYQs โ€” Photosynthesis in Higher Plants

11 Sign up to access

Showing 3 of 11 questions. Sign up to practice all with answers, explanations, and AI help.

NEET 2026Set 11MediumQ1

How many ATP and NADPH molecules are required to make one molecule of glucose through the Calvin pathway?

NEET 2026Set 11EasyQ2

The enzyme required for carboxylation in the Calvin cycle is

NEET 2026Set 11MediumQ3

Find the incorrect statement(s) about photosynthesis from the following: A. The water splitting complex is associated with PS I. B. C$_4$ plants use the C$_3$ pathway of CO$_2$ fixation as the main biosynthetic pathway. C. In C$_4$ plants, photorespiration does not occur. D. C$_3$ plants exhibit 'Kranz' anatomy. E. ATP synthesis in chloroplast occurs through chemiosmosis. Choose the answer from the options given below:

Free for all NEET aspirants

Unlock the full Photosynthesis in Higher Plants experience

All diagrams, videos, quick revision, PYQ practice with AI explanations โ€” plus mock tests, flashcards, and a personalised study plan.
