NEET Biology · NCERT Class 11

Photosynthesis in Higher Plants notes

Photosynthetic Pigments, Light Reaction, Electron Transport, Calvin Cycle, C₄ Pathway & Photorespiration and Factors Affecting Photosynthesis — explained topic by topic with key points, formulas, memory tricks and common mistakes.

  • 7 topics
  • 53 min read
  • 17 formulas
  • 107 PYQs
1

Chapter Overview

6 min

Photosynthesis is the anabolic process by which green plants use light energy to synthesize carbohydrates from carbon dioxide and water. In higher plants, it occurs mainly in chloroplasts of mesophyll cells. The chapter begins with photosynthetic pigments and chloroplast structure, then explains light reactions in thylakoid membranes where ATP, NADPH and oxygen are produced. The Calvin cycle in the stroma uses ATP and NADPH to reduce CO2 into sugars. C4 plants show special adaptations such as Kranz anatomy to reduce photorespiration. The rate of photosynthesis depends on light, CO2, temperature and water, according to Blackman’s law of limiting factors. For NEET, focus on sites, products, pigment spectra, Z-scheme, chemiosmosis, ATP/NADPH requirements, C3 vs C4 differences and limiting-factor graphs.

Key points6

  • Photosynthesis is not a single reaction but a coordinated sequence of photochemical and biochemical events.
  • Chlorophyll a is the chief pigment; accessory pigments broaden the absorption range and protect chlorophyll.
  • Oxygen released during photosynthesis comes from water, not carbon dioxide.
  • Non-cyclic photophosphorylation produces ATP, NADPH and O2; cyclic photophosphorylation produces only ATP.
  • C4 plants are more efficient under high temperature, intense light and low CO2 because photorespiration is minimized.
  • NEET questions commonly test exact sites, sequence of electron carriers, ATP/NADPH calculations and graphs.

Memory tricks2

Chapter Order Trick: Remember: Pigments Pick Light, Electrons Energize, Calvin Creates Carbs, C4 Cuts Photorespiration, Factors Fix Rate.

Products Split: Light reaction gives the ‘power’ ATP and NADPH; dark reaction uses that power to build sugar.

Examples2

Crop Productivity

A wheat field has C3 photosynthesis, while maize and sugarcane use C4 photosynthesis, giving better performance in hot bright conditions.

Aquarium Bubbles

In bright light, aquatic plants release visible oxygen bubbles because photolysis of water is active.

Common mistakes2

Calling Calvin Cycle a Dark Reaction

It does not directly need light, but it normally occurs in light because ATP and NADPH are supplied by the light reaction.

Wrong Oxygen Source

The oxygen evolved in photosynthesis comes from water, proved by isotope experiments, not from CO2.

Reference tables1

Quick revision7

Formulas2

Overall Photosynthesis Equation
6CO2+12H2O+ light energy →C6H12O6+6O2+6H2O6CO2 + 12H2O +\text{ light energy }→ C6H12O6 + 6O2 + 6H2O

Represents oxygenic photosynthesis in green plants. The oxygen released is derived from water.

CO2
Carbon dioxide fixed into carbohydrate
H2O
Electron donor split during photolysis
C6H12O6
Glucose or carbohydrate product
O2
Oxygen released from water
1 more formula — sign up free

Diagrams3

2

Photosynthetic Pigments

7 min

Photosynthesis in higher plants occurs mainly in chloroplasts of mesophyll cells. A chloroplast has a double membrane, stroma, grana and thylakoids. The light reactions occur on thylakoid membranes because they contain photosynthetic pigments and electron carriers. The Calvin cycle occurs in the stroma. Pigments include chlorophyll a, chlorophyll b, xanthophylls and carotenoids. Chlorophyll a is the chief pigment, while accessory pigments transfer absorbed light energy to it and protect chlorophyll from photo-oxidation. The absorption spectrum shows wavelengths absorbed by pigments, while the action spectrum shows wavelengths most effective for photosynthesis. Red and blue light are most effective, while green light is least effective because it is mostly reflected.

Key points6

  • The thylakoid membrane is the functional platform for PS I, PS II, electron transport chain and ATP synthase.
  • Grana increase surface area for light harvesting and photochemical reactions.
  • Accessory pigments broaden the useful range of light and prevent photo-oxidative damage.
  • Chlorophyll a absorbs mainly blue-violet and red light.
  • Action spectrum roughly resembles the absorption spectrum of chlorophyll a but also reflects accessory pigment contribution.
  • NCERT highlight: Engelmann’s experiment showed maximum oxygen evolution in blue and red regions.

Memory tricks2

Pigment Order: Remember ‘A is Actual, B is Backup’: chlorophyll a is chief; chlorophyll b supports it.

Spectra Trick: Plants look green because green is rejected/reflected; blue and red are used best.

Examples2

Why Leaves Are Green

Leaves appear green because chlorophyll absorbs red and blue light strongly but reflects/transmits much of the green light.

Red-Blue Grow Lights

Artificial plant growth lamps often use red and blue wavelengths because they match the peaks of photosynthetic action.

Common mistakes2

Absorption Spectrum vs Action Spectrum

Absorption spectrum shows light absorbed by pigment; action spectrum shows rate/effectiveness of photosynthesis.

Chloroplast Site Confusion

Do not place Calvin cycle in thylakoid. It occurs in stroma, while light reaction occurs on thylakoid membrane.

Reference tables2

Quick revision7

Formulas2

Photon Energy
E=hc/λE = hc/λ

Energy of light is inversely proportional to wavelength. Shorter wavelength blue light has higher energy than red light.

E
Energy of one photon
h
Planck’s constant
c
Speed of light
λ
Wavelength of light
1 more formula — sign up free

Diagrams3

3

Light Reaction

8 min

The light reaction is the photochemical phase of photosynthesis and occurs in thylakoid membranes. It begins when light excites reaction centre chlorophylls in photosystems. PS II has reaction centre P680 and absorbs light first in non-cyclic electron flow. Electrons lost by PS II are replaced by photolysis of water, releasing oxygen and protons. Electrons move through carriers, helping pump protons into the thylakoid lumen. PS I has reaction centre P700; it re-excites electrons and transfers them to NADP+, forming NADPH. The proton gradient drives ATP synthase to produce ATP by photophosphorylation. Non-cyclic photophosphorylation gives ATP, NADPH and O2, while cyclic photophosphorylation around PS I produces only ATP.

Key points6

  • Photosystems contain antenna pigments and a reaction centre chlorophyll a molecule.
  • In non-cyclic photophosphorylation, electrons move from water to NADP+ and do not return to chlorophyll.
  • Oxygen evolution is linked to PS II and photolysis of water.
  • Cyclic photophosphorylation supplements ATP when extra ATP is required.
  • ATP and NADPH produced in light reaction are used in Calvin cycle.
  • NEET often asks the exact products of cyclic vs non-cyclic photophosphorylation.

Memory tricks2

PS Order Trick: In non-cyclic flow, PS II acts before PS I: remember ‘Two before One in the light run’.

Cyclic Product Trick: Cyclic has a Circle: electron Comes back, so only ATP is Created.

Examples2

Solar Battery Analogy

The light reaction works like charging batteries: ATP and NADPH store usable energy for sugar synthesis.

Oxygen Evolution

Oxygen bubbles from Hydrilla in sunlight indicate active PS II-linked water splitting.

Common mistakes2

Assuming PS I Comes First

Although named PS I because it was discovered first, in non-cyclic electron flow PS II functions before PS I.

Adding Oxygen to Cyclic Flow

Cyclic photophosphorylation does not split water, so it does not produce oxygen or NADPH.

Reference tables2

Quick revision7

Formulas2

Photolysis of Water
2H2O→4H++4e−+O22H2O → 4H+ + 4e− + O2

Water is split in association with PS II to replace lost electrons and release oxygen.

H2O
Source of electrons and oxygen
H+
Protons contributing to proton gradient
e−
Electrons supplied to PS II
O2
Oxygen evolved as by-product
1 more formula — sign up free

Diagrams3

4

Electron Transport

7 min

Electron transport in photosynthesis occurs through carriers embedded in the thylakoid membrane. In the Z-scheme, electrons from water enter PS II, are excited by light, pass through plastoquinone, cytochrome b6f and plastocyanin to PS I, are excited again and finally reduce NADP+ through ferredoxin and NADP+ reductase. As electrons move through the chain, protons accumulate inside the thylakoid lumen due to water splitting and proton pumping. This creates a proton gradient: high H+ inside the lumen and lower H+ in the stroma. ATP synthase uses this gradient to synthesize ATP, a process called chemiosmosis. The CF0 part forms the channel and CF1 catalytic head faces the stroma.

Key points6

  • Water splitting increases H+ concentration in the lumen.
  • Cytochrome b6f contributes to proton gradient formation.
  • NADP+ reduction removes protons from the stroma, strengthening the gradient.
  • ATP is produced on the stromal side because CF1 faces stroma.
  • The proton gradient has both concentration and charge components.
  • Frequently asked NEET concept: ATP and NADPH are formed on the outer/stromal side of thylakoid membrane.

Memory tricks2

Carrier Sequence: Water → PSII → PQ → Cyt → PC → PSI → Fd → NADP. Remember: ‘Water Pumps Pretty Cycles, Plants Shine For NADPH’.

ATP Synthase Sides: CF1 faces stroma: ‘1 makes ATP for the outside stroma’.

Examples2

Dam Analogy

The thylakoid membrane acts like a dam: stored proton pressure is released through ATP synthase to make ATP.

Mobile Carriers

Plastoquinone and plastocyanin behave like delivery vehicles carrying electrons between large complexes.

Common mistakes2

Wrong Proton Direction

Protons accumulate inside the lumen and flow back to stroma through ATP synthase.

Forgetting NADP+ Reductase

Ferredoxin does not directly become NADPH; NADP+ reductase catalyzes the final reduction.

Reference tables2

Quick revision7

Formulas2

Chemiosmotic ATP Formation
ADP+Pi+ proton motive force →ATP+H2OADP + Pi +\text{ proton motive force }→ ATP + H2O

ATP synthase converts the energy of H+ movement into ATP.

ADP
Adenosine diphosphate
Pi
Inorganic phosphate
proton motive force
Energy stored in H+ gradient
ATP
Energy-rich molecule produced
1 more formula — sign up free

Diagrams3

5

Calvin Cycle

8 min

The Calvin cycle, also called the C3 pathway, is the carbon fixation phase of photosynthesis and occurs in the stroma of chloroplasts. It uses ATP and NADPH produced in the light reaction to convert CO2 into carbohydrate. The first stable product is 3-phosphoglyceric acid, a three-carbon compound, so it is called the C3 pathway. The cycle has three phases: carboxylation, reduction and regeneration. In carboxylation, RuBisCO fixes CO2 to RuBP, forming 3-PGA. In reduction, ATP and NADPH convert 3-PGA into triose phosphate. Some triose phosphate exits to form sugars, while most is used to regenerate RuBP. For 3 CO2, the cycle uses 9 ATP and 6 NADPH and produces one net triose phosphate.

Key points6

  • RuBisCO has both carboxylase and oxygenase activity; oxygenase activity causes photorespiration.
  • ATP is used in both reduction and regeneration phases.
  • NADPH is used only in the reduction phase.
  • Only a small fraction of triose phosphate exits the cycle; the rest regenerates RuBP.
  • The Calvin cycle depends indirectly on light because ATP and NADPH come from light reactions.
  • NEET often tests ATP/NADPH requirement for 1 CO2, 3 CO2 and 6 CO2.

Memory tricks2

Three Phases: Calvin cycle phases: C-R-R = Carboxylation, Reduction, Regeneration.

Energy Count: For C3: per CO2 remember ‘3 ATP, 2 NADPH’; multiply by 3 or 6 for triose or glucose.

Examples2

Wheat and Rice

Wheat and rice are common C3 plants; their CO2 fixation directly uses the Calvin cycle in mesophyll chloroplasts.

Sugar Formation

The Calvin cycle first produces triose phosphate, which can be converted into sucrose for transport or starch for storage.

Common mistakes2

Wrong First Product

In C3 plants, the first stable product is 3-PGA, not glucose.

Forgetting Regeneration ATP

ATP is used not only in reduction but also in regeneration of RuBP.

Reference tables2

Quick revision7

Formulas3

Carboxylation Reaction
RuBP +CO2+H2O→2 molecules of 3−PGA\text{RuBP }+ CO2 + H2O → 2\text{ molecules of }3-PGA

RuBisCO catalyzes addition of carbon dioxide to RuBP, producing two 3-carbon molecules.

RuBP
Ribulose-1,5-bisphosphate, 5-carbon CO2 acceptor
CO2
Carbon dioxide being fixed
3-PGA
3-phosphoglyceric acid, first stable product
Requirement for One CO2
1CO2 fixation requires 3ATP+2NADPH1CO2\text{ fixation requires }3ATP + 2\text{NADPH}

Useful for quick NEET calculations in the Calvin cycle.

CO2
One molecule of carbon dioxide entering the cycle
ATP
Energy used in reduction and RuBP regeneration
NADPH
Reducing power for converting 3-PGA to triose phosphate
1 more formula — sign up free

Diagrams3

6

C₄ Pathway & Photorespiration

9 min

The C4 pathway, also called Hatch–Slack cycle, is an adaptation that concentrates CO2 around RuBisCO and minimizes photorespiration. It occurs in plants such as maize, sugarcane and sorghum. C4 leaves show Kranz anatomy, where bundle sheath cells form a wreath-like arrangement around vascular bundles and contain abundant chloroplasts. In mesophyll cells, PEP carboxylase fixes CO2 into oxaloacetic acid, a four-carbon compound, which is converted to malate or aspartate and transported to bundle sheath cells. There, CO2 is released and enters the Calvin cycle. Photorespiration occurs when RuBisCO binds O2 instead of CO2, wasting energy and releasing CO2. CAM plants, such as cactus, separate CO2 fixation and Calvin cycle by time, opening stomata at night.

Key points6

  • PEP carboxylase has high affinity for CO2 and no oxygenase activity.
  • C4 plants avoid photorespiration by increasing CO2 concentration near RuBisCO.
  • C4 photosynthesis requires extra ATP compared with C3 photosynthesis.
  • Bundle sheath cells in C4 plants are rich in chloroplasts and often have reduced grana.
  • Photorespiration reduces photosynthetic efficiency because it consumes oxygen and releases CO2 without producing ATP or sugar.
  • CAM is a water-saving adaptation common in xerophytes.

Memory tricks3

C4 Core: C4 = 4-carbon first product, 4 hot crops: maize, sugarcane, sorghum, millet.

Kranz Meaning: Kranz sounds like ‘crown’; bundle sheath cells form a crown around the vascular bundle.

CAM Timing: CAM plants are ‘Cool At Midnight’: they open stomata at night.

Examples2

Sugarcane

Sugarcane is a C4 plant, explaining its high productivity under tropical sunlight.

Cactus

Cactus uses CAM photosynthesis to reduce water loss by opening stomata at night.

Common mistakes3

Putting Calvin Cycle in Mesophyll of C4 Plants

In typical C4 plants, initial fixation occurs in mesophyll, but Calvin cycle occurs in bundle sheath cells.

Saying C4 Has No Calvin Cycle

C4 plants still use the Calvin cycle; they only add a CO2-concentrating mechanism before it.

Confusing C4 and CAM

C4 separates steps by space; CAM separates steps by time.

Reference tables2

Quick revision7

Formulas3

C4 Initial Fixation
PEP+HCO3−→ OxaloacetatePEP + HCO3− →\text{ Oxaloacetate}

PEP carboxylase fixes bicarbonate in mesophyll cells to form the first stable C4 acid.

PEP
Phosphoenolpyruvate, 3-carbon CO2 acceptor
HCO3−
Bicarbonate form of inorganic carbon
Oxaloacetate
First stable 4-carbon product
Photorespiration Trigger
RuBP +O2→3−PGA+2−phosphoglycolate\text{RuBP }+ O2 → 3-PGA + 2-\text{phosphoglycolate}

When RuBisCO acts as oxygenase, photorespiratory metabolism begins.

RuBP
5-carbon substrate of RuBisCO
O2
Oxygen competing with CO2
3-PGA
Useful Calvin cycle intermediate
2-phosphoglycolate
Photorespiratory product requiring recovery
1 more formula — sign up free

Diagrams3

7

Factors Affecting Photosynthesis

8 min

The rate of photosynthesis depends on internal factors such as chlorophyll content, leaf anatomy and enzyme activity, and external factors such as light, carbon dioxide, temperature and water. Light affects intensity, quality and duration; rate increases with light intensity until saturation. CO2 concentration is often limiting in nature because atmospheric CO2 is low. Temperature affects enzyme-controlled dark reactions more than photochemical light reactions. Water indirectly affects photosynthesis by causing stomatal closure, reducing CO2 entry and decreasing leaf hydration. Blackman’s law of limiting factors states that when a process is controlled by multiple factors, the rate is governed by the factor nearest to its minimum. NEET frequently asks graph interpretation: a plateau means another factor has become limiting.

Key points6

  • At low light, light is limiting; at high light, CO2 or temperature may become limiting.
  • CO2 enrichment can increase photosynthesis, especially in C3 plants.
  • C4 plants have higher optimum temperature than C3 plants.
  • Very high light can damage pigments due to photo-oxidation.
  • Water is rarely a direct reactant-limiting factor because only a small amount is used, but it strongly affects stomata.
  • Limiting-factor graphs are highly important for NEET assertion-reason and statement questions.

Memory tricks2

Major External Factors: Remember LCTW: Light, Carbon dioxide, Temperature, Water.

Blackman’s Law: Photosynthesis is like a chain: the weakest link decides the strength.

Examples3

Greenhouse CO2 Enrichment

Farmers may increase CO2 concentration in greenhouses to raise photosynthetic rate when light and temperature are adequate.

Midday Depression

On hot dry days, stomata may close at noon, reducing CO2 entry and lowering photosynthesis despite strong sunlight.

Shade Leaves

Plants growing in shade adapt to lower light intensity and may saturate at lower light levels than sun plants.

Common mistakes3

Misreading Plateau

A plateau does not mean photosynthesis has stopped; it means another factor is now limiting.

Thinking Water Directly Limits Usually

Water is a reactant, but its major limiting effect is indirect through stomatal closure and reduced CO2 entry.

Ignoring Temperature Optimum

Very high temperature does not always increase photosynthesis; enzymes may lose activity and photorespiration may rise.

Reference tables2

Quick revision7

Formulas3

Blackman’s Law Concept
Rate of photosynthesis = rate allowed by the most limiting factor\text{Rate of photosynthesis }=\text{ rate allowed by the most limiting factor}

The slowest or least available required factor controls the overall photosynthetic rate.

Rate
Observed photosynthetic output
Limiting factor
Factor closest to minimum requirement
Apparent Photosynthesis
Apparent photosynthesis = True photosynthesis − Respiration\text{Apparent photosynthesis }=\text{ True photosynthesis }-\text{ Respiration}

Measured net oxygen release or CO2 uptake is lower than true photosynthesis because respiration occurs simultaneously.

Apparent photosynthesis
Net measurable photosynthetic rate
True photosynthesis
Total photosynthetic carbon fixation
Respiration
CO2 release or O2 consumption by cellular respiration
1 more formula — sign up free

Diagrams5

Videos for Photosynthesis in Higher Plants

  • Photosynthesis in Higher Plants One ShotVedantu NEET English · English
  • Photosynthesis in Higher Plants 🌿Vedantu NEET English · English
  • PHOTOSYNTHESIS IN HIGHER PLANTSPW NEET English · English
  • Photosynthesis | Part-1Vedantu NEET English · English
  • Photosynthesis | Part -2Vedantu NEET English · English
Watch with a free account

NEET PYQs from Photosynthesis in Higher Plants

The latest 3 of 107 previous-year questions from this chapter.

  1. NEET 2026Set 11MediumQ1

    How many ATP and NADPH molecules are required to make one molecule of glucose through the Calvin pathway?

    • A18 ATP and 12 NADPH
    • B12 ATP and 18 NADPH
    • C24 ATP and 18 NADPH
    • D6 ATP and 12 NADPH
  2. NEET 2026Set 11EasyQ2

    The enzyme required for carboxylation in the Calvin cycle is

    • AHexokinase
    • BPEP carboxylase
    • CRuBP carboxylase-oxygenase
    • DCarboxypeptidase
  3. NEET 2026Set 11MediumQ3

    Find the incorrect statement(s) about photosynthesis from the following: A. The water splitting complex is associated with PS I. B. C$_4$ plants use the C$_3$ pathway of CO$_2$ fixation as the main biosynthetic pathway. C. In C$_4$ plants, photorespiration does not occur. D. C$_3$ plants exhibit 'Kranz' anatomy. E. ATP synthesis in chloroplast occurs through chemiosmosis. Choose the answer from the options given below:

    • AB and C only
    • BB only
    • CB and E only
    • DA and D only

Get the whole of Photosynthesis in Higher Plants

A free account opens every formula, diagram, table and quick-revision list in this chapter, and tracks the topics you finish.

  • Free to start
  • Progress saved per topic
  • PYQ practice for Photosynthesis in Higher Plants
