6📖 1. Chapter Overview
Overview
This chapter explains how humans obtain oxygen and remove carbon dioxide through breathing, diffusion, transport and regulation. The respiratory system includes nostrils, nasal chamber, pharynx, larynx, trachea, bronchi, bronchioles and lungs, ending in alveoli where gas exchange occurs. Breathing is caused by pressure changes produced by diaphragm and intercostal muscles. Oxygen and carbon dioxide diffuse according to partial pressure gradients at alveoli and tissues. Oxygen is mainly carried as oxyhaemoglobin, while carbon dioxide is mostly transported as bicarbonate ions. Respiratory centres in the medulla and pons regulate rhythm, especially by sensing carbon dioxide and hydrogen ion levels. NEET commonly tests respiratory volumes, partial pressure tables, chloride shift, oxyhaemoglobin dissociation curve and disorders like asthma, emphysema and occupational lung diseases.
- 1Respiratory exchange has four linked steps: breathing, alveolar diffusion, blood transport and tissue diffusion.
- 2Partial pressure differences, not concentration alone, decide direction of gas diffusion.
- 3Haemoglobin saturation depends on pO2, pCO2, H+ concentration and temperature.
- 4Carbonic anhydrase in RBCs rapidly converts CO2 and water into carbonic acid.
- 5Chloride shift maintains ionic balance when bicarbonate leaves RBCs.
- 6Regulation of respiration is mainly neural, modified by chemical feedback.
Chapter Sequence Trick
Remember O-B-E-T-R-D: Organs → Breathing → Exchange → Transport → Regulation → Disorders.
CO2 Controls Breathing
Think 'CO2 is the Captain' because CO2/H+ rise is the strongest normal stimulus for breathing.
Exercise
During running, muscles produce more CO2 and H+, stimulating respiratory centres to increase breathing rate and depth.
High Altitude
At high altitude atmospheric pO2 falls, so oxygen diffusion into blood becomes harder and breathing rate increases.
Breathing vs Cellular Respiration
Breathing is ventilation of lungs; cellular respiration is oxidation of food inside cells to release energy.
Direction of Diffusion
Do not memorize arrows blindly. Always compare partial pressures: gas moves from higher partial pressure to lower partial pressure.
Carbon Dioxide Transport
NEET often traps students into saying most CO2 binds haemoglobin. Actually most CO2 travels as bicarbonate ions.
Total volume of air breathed in or out per minute; useful for estimating ventilation efficiency.
Variables
Tidal volume=Volume of air inspired or expired in a normal breath, about 500 mL
Respiratory rate=Number of breaths per minute, usually 12 to 16 in healthy adults
🫁 2. Respiratory Organs
Overview
The human respiratory system is designed to conduct, condition and exchange respiratory gases. Air enters through nostrils, passes into the nasal chamber, pharynx, larynx, trachea, bronchi and bronchioles, finally reaching alveoli. The conducting part transports air and removes dust using mucus and cilia, while the respiratory part includes alveoli where diffusion occurs. Lungs are paired, spongy organs present in the thoracic chamber, protected by ribs and covered by pleura. Pleural fluid reduces friction and helps lung movement during breathing. Alveoli are thin-walled, moist and surrounded by capillaries, giving a large surface for exchange. Respiratory volumes such as tidal volume, inspiratory reserve volume, expiratory reserve volume and residual volume combine to form capacities like vital capacity and total lung capacity.
- 1Nasal passage warms, moistens and filters inspired air.
- 2Larynx contains vocal cords and guards the entrance to trachea.
- 3Trachea and bronchi are supported by incomplete cartilaginous rings to prevent collapse.
- 4Alveolar walls and capillary walls together form the respiratory membrane.
- 5Lungs lie in an airtight thoracic chamber bounded by ribs, sternum, vertebral column and diaphragm.
- 6Spirometer can measure most respiratory volumes except residual volume directly.
Air Path
No Naughty People Like To Blow Balloons Always: Nostrils, Nasal chamber, Pharynx, Larynx, Trachea, Bronchi, Bronchioles, Alveoli.
Capacity Formulas
IC is 'In Comes' air: TV + IRV. VC is 'Very Complete' expiration: IRV + TV + ERV.
Spirometry
A doctor asks a patient to breathe into a spirometer to assess tidal volume and vital capacity.
Mucus and Cilia
Dust in inhaled air is trapped by mucus and moved upward by cilia, explaining why polluted air irritates the airway.
Residual Volume
Residual volume cannot be expired even after forceful expiration and is not directly measured by a simple spirometer.
Alveoli vs Bronchioles
Bronchioles conduct air; alveoli exchange gases. Do not call bronchioles the main exchange site.
Pleura Function
Pleura is not a gas exchange surface; it reduces friction and supports lung expansion.
Maximum volume of air a person can inspire after a normal expiration.
Variables
IC=Inspiratory capacity
TV=Tidal volume, about 500 mL
IRV=Inspiratory reserve volume, about 2500 to 3000 mL
Total volume of air a person can expire after a normal inspiration.
Variables
EC=Expiratory capacity
TV=Tidal volume
ERV=Expiratory reserve volume, about 1000 to 1100 mL
🌬️ 3. Mechanism of Breathing
Overview
Breathing or pulmonary ventilation is the movement of air into and out of lungs due to pressure differences between atmosphere and alveoli. Inspiration is an active process in normal breathing. The diaphragm contracts and becomes flat, external intercostal muscles lift ribs and sternum, thoracic volume increases and intrapulmonary pressure falls below atmospheric pressure, so air enters. Expiration during quiet breathing is mostly passive. Diaphragm and external intercostals relax, ribs and sternum return, thoracic volume decreases, intrapulmonary pressure rises above atmospheric pressure and air moves out. Forced expiration uses internal intercostal and abdominal muscles. The key NEET logic is inverse relation between volume and pressure: increase in thoracic volume decreases pulmonary pressure; decrease in volume increases pulmonary pressure.
- 1Lungs cannot expand by themselves; they follow thoracic wall movement due to pleural linkage.
- 2The diaphragm is the major muscle of inspiration.
- 3Intercostal muscles mainly change antero-posterior and lateral diameter of thorax.
- 4Intrapleural pressure remains lower than atmospheric pressure and helps keep lungs expanded.
- 5Breathing rhythm consists of inspiration followed by expiration.
- 6During exercise, both rate and depth of breathing increase.
Inspiration Rule
I-V-P-A: Inspiration means Volume increases, Pressure decreases, Air enters.
Expiration Rule
E-V-P-A: Expiration means Volume decreases, Pressure increases, Air exits.
Deep Breath
When taking a deep breath before swimming, the diaphragm contracts more strongly and inspiratory reserve volume is used.
Coughing
Coughing uses forceful expiration, so abdominal and internal intercostal muscles actively compress the thoracic cavity.
Diaphragm Direction
Do not say diaphragm moves upward during inspiration. During inspiration it contracts, flattens and moves downward.
Pressure Confusion
Air does not enter because lungs 'pull' air directly; it enters because intrapulmonary pressure becomes lower than atmospheric pressure.
Expiration Always Active
Quiet expiration is passive, but forced expiration is active and uses internal intercostal and abdominal muscles.
At constant temperature, pressure of gas decreases when volume increases and increases when volume decreases.
Variables
P=Pressure inside lungs
V=Volume of thoracic cavity or lungs
Air enters when atmospheric pressure is greater than alveolar pressure and leaves when alveolar pressure is greater.
Variables
Patm=Atmospheric pressure
Palv=Alveolar or intrapulmonary pressure
🔄 4. Gas Exchange
Overview
Gas exchange occurs by simple diffusion across thin respiratory membranes and depends mainly on partial pressure gradients. In alveoli, pO2 is higher than in deoxygenated blood, so oxygen diffuses from alveolar air into blood. pCO2 is higher in deoxygenated blood than in alveolar air, so carbon dioxide diffuses from blood into alveoli. In tissues, the reverse happens: tissue pO2 is lower than blood pO2, so oxygen enters tissues; tissue pCO2 is higher, so carbon dioxide enters blood. Exchange is efficient because alveoli have a huge surface area, thin squamous epithelium, moist surface, rich capillary supply and a short diffusion distance. NEET often asks the partial pressures in alveoli, blood and tissues and the factors affecting diffusion.
- 1Partial pressure is the pressure contributed by an individual gas in a mixture.
- 2Respiratory membrane includes alveolar epithelium, basement substance and capillary endothelium.
- 3Blood leaving alveoli becomes oxygenated and has high pO2.
- 4Blood reaching tissues delivers oxygen because tissue pO2 is low.
- 5High thickness of respiratory membrane reduces gas exchange, as in fibrosis or pneumonia.
- 6A steep pressure gradient is essential for rapid diffusion.
Alveoli Direction
At Alveoli: O2 is Out of air into blood; CO2 Comes Out of blood.
Tissue Direction
At Tissues: O2 goes To tissue; CO2 comes To blood.
Pneumonia
Fluid and inflammation thicken the diffusion barrier, reducing oxygen entry into blood.
Emphysema
Loss of alveolar walls reduces surface area, decreasing efficiency of gas exchange.
Using Total Pressure
Gas exchange depends on partial pressure of each gas, not total air pressure alone.
CO2 Diffusion
Even though pCO2 gradient is smaller than pO2 gradient, CO2 diffuses efficiently because it is more soluble.
Alveoli vs Atmospheric Air
Alveolar air has lower pO2 and higher pCO2 than atmospheric air because it mixes with residual air and exchanges gases continuously.
Gas diffusion increases with surface area, diffusion coefficient and pressure gradient but decreases with membrane thickness.
Variables
A=Surface area of respiratory membrane
D=Diffusion coefficient of gas
ΔP=Partial pressure difference
T=Thickness of diffusion membrane
🩸 5. Gas Transport
Overview
Blood transports respiratory gases between lungs and tissues. About 97 percent of oxygen is carried by haemoglobin as oxyhaemoglobin, while about 3 percent is dissolved in plasma. Each haemoglobin molecule can bind four oxygen molecules. Oxygen loading occurs in lungs where pO2 is high, and unloading occurs in tissues where pO2 is low, pCO2 is high, H+ concentration is high and temperature is higher. This is shown by the sigmoid oxyhaemoglobin dissociation curve. Carbon dioxide is transported in three forms: dissolved in plasma, bound to haemoglobin as carbaminohaemoglobin and mainly as bicarbonate ions. In RBCs, carbonic anhydrase catalyses CO2 hydration. Bicarbonate exits RBCs into plasma and chloride ions enter RBCs to maintain electrical balance; this is called chloride shift.
- 1High pO2, low pCO2, low H+ and lower temperature favour oxyhaemoglobin formation in lungs.
- 2Low pO2, high pCO2, high H+ and higher temperature favour oxygen dissociation in tissues.
- 3CO2 can bind to globin part of haemoglobin, not the haem iron used by oxygen.
- 4Bicarbonate transport is the major route for CO2 because carbonic anhydrase makes the reaction fast.
- 5Chloride shift is also called Hamburger phenomenon.
- 6Oxyhaemoglobin curve helps explain oxygen loading, unloading and exercise adaptation.
O2 Loading Conditions
Lungs are 'High O2, Low CO2, Cool and Calm' so haemoglobin holds oxygen.
O2 Unloading Conditions
Tissues are 'Hot, acidic and CO2-rich' so haemoglobin releases oxygen.
CO2 Forms
Remember 7-23-70: dissolved, carbamino, bicarbonate.
Working Muscle
Exercising muscles produce heat, CO2 and lactic acid, shifting the curve right and increasing oxygen delivery.
Carbonic Anhydrase Importance
Without carbonic anhydrase, CO2 conversion to bicarbonate would be too slow to match tissue metabolism.
Haemoglobin Binding Site
Oxygen binds to haem iron; carbon dioxide binds mainly to globin amino groups.
Curve Shape
The oxyhaemoglobin dissociation curve is sigmoid, not straight, due to cooperative binding.
Chloride Shift Direction
In tissues, bicarbonate leaves RBC and chloride enters RBC. In lungs, the reverse occurs.
Major CO2 Form
Most CO2 is not dissolved in plasma; it is transported as bicarbonate.
Haemoglobin reversibly combines with oxygen; forward reaction dominates in lungs and reverse reaction in tissues.
Variables
Hb=Haemoglobin
O2=Oxygen molecule
Hb(O2)4=Fully oxygenated haemoglobin
Carbonic anhydrase in RBCs catalyses formation of carbonic acid and bicarbonate ions.
Variables
CO2=Carbon dioxide from tissues
H2O=Water
H2CO3=Carbonic acid
HCO3−=Bicarbonate ion transported in plasma
🧠 6. Regulation of Respiration
Overview
Respiration is regulated mainly by neural centres in the brain, with chemical feedback modifying the rhythm. The respiratory rhythm centre in the medulla generates the basic breathing rhythm. The pneumotaxic centre in the pons can reduce the duration of inspiration and thereby alter respiratory rate. Chemosensitive areas near the respiratory centre are highly sensitive to carbon dioxide and hydrogen ions. Peripheral chemoreceptors in the carotid and aortic bodies also sense changes in CO2, H+ and oxygen, though oxygen usually becomes a major stimulus only when it falls significantly. During exercise, increased CO2, H+, temperature and neural signals from muscles increase ventilation. The goal of regulation is to maintain proper blood pO2, pCO2 and pH.
- 1Medullary centres maintain automatic rhythmic breathing even during sleep.
- 2Pons fine-tunes respiratory pattern rather than initiating the basic rhythm.
- 3CO2 crosses the blood-brain barrier and increases H+ in cerebrospinal fluid, stimulating breathing.
- 4Peripheral chemoreceptors help detect arterial blood gas changes.
- 5Stretch receptors in lungs can protect from overinflation in special conditions.
- 6Homeostasis of blood pH is tightly linked to ventilation.
Brain Centres
M makes rhythm: Medulla = Main rhythm. P makes pace: Pons = Pneumotaxic pacing.
Chemical Control
CO2-H+ is the emergency bell; when they rise, breathing rises.
Breath Holding
After holding your breath, CO2 builds up and strongly stimulates the medulla, forcing you to breathe.
Running
During running, muscles produce more CO2 and H+, so breathing becomes faster and deeper.
Oxygen as Main Regulator
Under normal conditions, CO2 and H+ regulate breathing more strongly than O2.
Pons Function
Pons does not create the basic rhythm; it modifies inspiration and respiratory rate.
Voluntary Control
You can hold breath temporarily, but rising CO2 eventually overrides voluntary control.
Increased CO2 increases H+ concentration and lowers pH, stimulating respiratory centres.
Variables
CO2=Carbon dioxide level in blood
H+=Hydrogen ion causing acidity
pH=Measure of acidity; falls when H+ rises
⚕️ 7. Respiratory Disorders
Overview
Respiratory disorders reduce ventilation, diffusion or oxygen delivery. Asthma is an allergic or inflammatory condition causing narrowing of bronchi and bronchioles, leading to wheezing and difficulty in breathing. Emphysema is a chronic disorder, commonly linked to cigarette smoking, in which alveolar walls are damaged and respiratory surface area decreases. Occupational respiratory disorders occur due to long exposure to dust in industries such as mining, stone grinding or asbestos work; inflammation and fibrosis reduce lung capacity. Pneumonia is infection and inflammation of alveoli, often causing fluid accumulation and poor gas exchange. Tuberculosis is a bacterial disease mainly affecting lungs, with chronic cough and systemic symptoms. NEET focuses on cause, affected part and physiological consequence.
- 1Airway obstruction mainly affects ventilation, while alveolar damage mainly affects diffusion.
- 2Asthma attacks are often reversible with proper treatment, but emphysema damage is largely irreversible.
- 3Fibrosis increases diffusion distance and reduces lung compliance.
- 4Pneumonia may reduce pO2 because alveoli are not properly ventilated or are fluid-filled.
- 5Tuberculosis spreads by droplets and needs proper antibiotic treatment.
- 6Protective masks and dust control are important in occupational lung disease prevention.
Disease-Affected Part
A-B, E-A: Asthma affects Bronchi; Emphysema affects Alveoli.
Occupation Clue
Dust does Damage: long-term industrial dust causes inflammation and fibrosis.
Asthma Trigger
A student exposed to pollen or dust may develop wheezing because bronchioles constrict and mucus increases.
Occupational Exposure
A miner inhaling dust for years may develop fibrotic lung disease and reduced breathing capacity.
Smoker’s Lung
A long-term smoker may develop emphysema where damaged alveoli cannot exchange gases efficiently.
Asthma vs Emphysema
Asthma is mainly airway narrowing; emphysema is alveolar wall destruction. Do not interchange them.
Smoking Link
For NEET, cigarette smoking is classically associated with emphysema.
Pneumonia Site
Pneumonia affects alveoli and may fill them with fluid; it is not simply a tracheal disorder.
Occupational Disorders
The key mechanism is chronic dust exposure causing inflammation and fibrosis, not an immediate allergic attack only.
In emphysema, alveolar wall destruction lowers surface area and decreases diffusion.
Variables
Surface area=Available alveolar membrane area for gas exchange
Diffusion rate=Amount of gas crossing respiratory membrane per unit time
Formula Sheet
10Total volume of air breathed in or out per minute; useful for estimating ventilation efficiency.
Variables
Tidal volume=Volume of air inspired or expired in a normal breath, about 500 mL
Respiratory rate=Number of breaths per minute, usually 12 to 16 in healthy adults
Explains why thin, moist, vascular alveoli are efficient for exchange of gases.
Variables
Surface area=Total area available for gas exchange
Pressure gradient=Difference in partial pressure of gas across the membrane
Diffusion distance=Thickness of respiratory membrane
Maximum volume of air a person can inspire after a normal expiration.
Variables
IC=Inspiratory capacity
TV=Tidal volume, about 500 mL
IRV=Inspiratory reserve volume, about 2500 to 3000 mL
Total volume of air a person can expire after a normal inspiration.
Variables
EC=Expiratory capacity
TV=Tidal volume
ERV=Expiratory reserve volume, about 1000 to 1100 mL
Maximum volume of air a person can breathe out after a forceful inspiration.
Variables
VC=Vital capacity
IRV=Extra air inspired forcibly after normal inspiration
TV=Air in normal breath
ERV=Extra air expired forcibly after normal expiration
5 more formulas locked
Sign up free to access all formulas with variables and explanations.
Quick Revision
12 Sign up to accessUnlock 12 Quick Revision Points
Sign up free to access all content, practice PYQs, and get AI explanations.
NEET PYQs — Breathing and Exchange of Gases
11 Sign up to accessShowing 3 of 11 questions. Sign up to practice all with answers, explanations, and AI help.
Match List-I with List-II. Choose the correct answer from the options given below :
In humans, respiration occurs in the following steps. Arrange these steps in the correct order: A. Diffusion of O₂ and CO₂ between blood and tissues B. Diffusion of O₂ and CO₂ across alveolar membrane C. Pulmonary ventilation by which atmospheric air is drawn in and CO₂ rich alveolar air is released out D. Cellular respiration E. Transport of gases by the blood Choose the correct answer from the options given below:
The partial pressures (in mm Hg) of oxygen (O₂) and carbon dioxide (CO₂) at alveoli (the site of diffusion) are:
Unlock the full Breathing and Exchange of Gases experience
All diagrams, videos, quick revision, PYQ practice with AI explanations — plus mock tests, flashcards, and a personalised study plan.
